PLUG417S

Plug417S Infrared Module Specially Developed for IR Fever Sensing System

Features

  • Materials: VOx
  • Package: Metal
  • Pixel-pitch: 17μm
  • Resolution: 400X300
  • Spectra range:8μm -14μm
  • High sensitivity,NETD<30mK
  • Accuracy without blackbody ≤±0.5℃
  • Effective in 3.2X2.5 area and optimal at 5m distance
  • All in one USB3.0 interface: power + data + control
  • ARM or Windows based SDK for further development
  • Reserved seal groove for easy housing assembly
Send message to us

Description:

PLUG417S infrared module is specially developed for IR fever sensing system. It consists of 400×300@17μm infrared module , 9.7mm infrared optical lens and a specialized SDK for human body temperature measurement. The data captured by Plug417S can be tran-sferred to the back-end platform integration via a 50-pin or via USB3.0 interface. The dedicated SDK supports integrators to achieve temperature conversion, IR image display and many other functions. With such a well-functional IR module, the integrators could develop their own IR fever sensing system quickly and efficiently.

Application:

Video:

Specifications:

Model PLUG417S
IRDetectorPerformance
Resolution 400X300
Pixel Pitch 17μm
Spectral Range 8~14μm
NETD ＜30mK
ImageProcessing
  25Hz
Frame Rate ＜10S
Start-upTime USB video
Dimming Linear/Histogram/Mixed three modes
Image Display Black hot/White hot/Pseudo color
Image Direction  Horizontally/Vertically/Diagonally Flip
Image Algorithm NUC AGC IDE DNR
Electrical Specification
StandardExternalInterface TYPE-C
CommunicationMode USB
Supply Voltage 5±0.5V
TypicalPowerConsumption <1.5W
TemperatureMeasurement
Operating Temperature Range 16℃ ~ 32℃
Temperature Range 20℃ ~ 50℃
Temperature  Accuracy ≤±0.5℃（No wind indoors，32℃~42℃ Target）
SDK ARM/Windows SDK，full screen thermography
PhysicalCharacteristic
Dimension(mm) 44.5X42.5X58.9(PLUG417S+7mm lens）
Weight PLUG417S+7mm lens≤135g
Environmental
Operation Temperature -10°C ~ +50°C
Storage Temperature -45°C ~ +85°C
Humidity 5%~95%，non-condensing
Vibration Random Vibration 5.35grms，3 axis
Shock  half-sine wave，40g/11ms，3 axis 6 direction
Optics
Optional lens Fixed focus athermal：7mm
Certification
Certification standards ROHS/REACH

For more information, please click the button below to download a PDF of the product.
