C330S MW/LW dual-color is one of T2SL cooled infrared detectors developed by Global Sensor Technology (GST). It combines the advantages of both medium and long wave detection in one single 320x256@30µm infrared detector package for high performance imaging in the 3.7~4.8μm Medium Wave Infrared (MWIR) and 7.7~9.5μm Long Wave Infrared (LWIR) wavebands, which can greatly lower the false warning rate.
Each of the 320x256 pixels in the array can be switched between MWIR and LWIR sensitivity mode by changing the bias voltage on the device, ensuring spatial coherence between the two bands. Images / videos from both bands can be captured and output within a single frame period, optimizing the temporal coherence between bands. The frame frequency of both bands can be up to 100Hz for monitoring the high speed moving targets.
| Model | C330S MW/LW |
| Sensitive Material | T2SL |
| Resolution | 320×256 |
| Pixel Size | 30μm |
| Spectral Range |
MW: 3.7μm±0.2μm～4.8μm±0.2μm LW: 7.7μm±0.2μm～9.4μm±0.3μm |
| Working Mode | Snapshot; ITR Integration Mode; Windows Mode; Anti-blooming |
| Charge Capacity |
MW: 8.9Me-/3Me- LW: 21Me- |
| Dynamic Range |
MW: ≥76dB LW: ≥80dB |
| Number of Output | 1 or 4; Up to 12 MHz per Output |
| Typical NETD |
MW: 20mK LW: 25mK |
| Effective Pixel Rate | ≥99.0% |
| Response Non-uniformity | ≤8% |
| Cryocooler | RS058 |
| Steady Power Consumption | ≤9W |
| Max. Power Consumption | ≤18W |
| Power Supply | 24V DC |
| Cooling Time | ≤8min |
| Maximum Size (mm) | 142×58.5×71 |
| Weight | ≤600g |
| Operating Temperature | -45°C ~ +71°C |
For more information, please click the button below to download a PDF of the product.
Downloads
320×256 MW/LWIR Cooled Infrared detector
